The best Nexgrill drip tray replacement is the part listed for your exact grill model and production version. A tray that is roughly the right width can still have the wrong drain opening, cup holder or mounting edges. Start with the model label, including its letter suffix, then match the parts diagram.
These three choices cover specific Nexgrill applications. They are a comparison of documented parts and fit information, not a hands-on durability test. Nexgrill directs owners to My Grill Parts for official replacement parts.
Three Nexgrill grease trays worth checking
| Part | Documented example fit | Main buying point |
|---|---|---|
| 20003113A0 grease tray assembly | 720-0888, sold in 2020, US | Match the official model diagram; confirm dimensions with the supplier |
| 20003122A0 grease tray assembly | 720-0830H, sold in 2016, US | For the earlier catalog version; approximately 25 9/16 × 14 1/4 inches |
| 120850002459 grease tray assembly | 720-0830H, sold in 2024, US | Different part number despite the same approximate footprint |
1. Nexgrill 20003113A0: for listed 720-0888 versions
Choose this assembly when your grill’s parts list specifies 20003113A0. The US 2020 720-0888 catalog identifies it as the grease tray, diagram item 48. The part’s compatibility list also includes particular 720-0888A and 720-0958A versions; check the full model and year before extending that fit to your grill.
Why it makes the list: a traceable Nexgrill part number gives you a more useful starting point than a generic promise to fit five-burner grills. It replaces the large grease-collecting tray, rather than a disposable liner.
Limitation: published dimension fields for this part conflict across catalogs. Ask the supplier to confirm the tray’s outer footprint, edge profile and drain position against your old part before ordering. Do not use the burner count to settle the question. The 2020 diagram lists the grease cup separately, so check whether you need that component too.
Check Nexgrill 20003113A0 at My Grill Parts
2. Nexgrill 20003122A0: for the earlier 720-0830H catalog
The US 2016 720-0830H parts list assigns 20003122A0 to grease tray item 29. Its small grease box is a separate item 30, part 20003121A0.
Why choose it: this is the catalog match to investigate for that earlier grill version. My Grill Parts lists a 25.56 by 14.25 footprint, consistent with Appliance Factory Parts’ approximate 25 9/16 by 14 1/4-inch measurements. The retailer’s listing describes the material as not stainless; a silver-looking photo is not evidence of stainless-steel construction.
Limitation: it is not an automatic substitute for the later 120850002459 assembly. Confirm brackets, drain location and the correct grease box as well as length and width. An Amazon listing under the Appliance Factory Parts brand identifies the exact part number below; verify the seller’s included components before checkout.
Appliance Factory Parts 20003122A0 Grease Tray
As an Amazon Associate we earn from qualifying purchases.
3. Nexgrill 120850002459: for the US 2024 720-0830H
The US 2024 720-0830H catalog specifies 120850002459 as grease tray assembly item 33. The official part listing also names particular 720-0830HM and 720-0830X versions.
Why choose it: it follows the later catalog’s part assignment. The official catalog gives the same 25.56 by 14.25 footprint as the earlier tray, while Appliance Factory Parts lists approximately 25 9/16 by 14 1/4 inches. This is a useful example of why measurements alone cannot establish interchangeability.
Limitation: the 2024 catalog separately specifies grease cup 120870002310, item 34. Do not assume the cup comes with the tray assembly. The Amazon listing below identifies tray 120850002459 under the Appliance Factory Parts brand; its photo includes a wire holder, not a collection cup. Check current stock and package contents with the selected supplier.
Check these details before buying
- Model, suffix and version: match the label and your manual. The catalog’s “sold in” year is a version identifier, not necessarily the year you bought the grill.
- Tray versus cup: the broad tray directs drippings into a smaller cup or box. A liner, cooking sheet or automotive drain pan does not replace the grill’s specified assembly.
- Fit: compare the outer length and width, flange shape, support rails, drain opening and cup attachment. If a listing disagrees with your part, have Nexgrill or the supplier resolve it before ordering.
- Condition: inspect the tray supports as well as the pan. Replacing a tray does not repair rusted or damaged mounting points.
Keep the replacement working properly
Follow the care instructions for your exact grill. Nexgrill’s 720-0830H manual says to let hot grease cool before handling it, clean the grease tray regularly, and prevent grease from accumulating or overflowing. Turn off the grill and gas supply and let everything cool before removing parts. Refit the correct tray and cup securely before cooking. Avoid improvised supports or changes to the drainage path.
